Distance

Visible light

1000m

Human

(1.8m×0.5m)

Detect

2910m

Recognise

730m

Identificate

360m

Vehicle

(2.3m×2.3m)

Detect

8320m

Recognize

2080m

Identificate

1040m

Detector

Sensor

Uncooled infrared focal plane detector（vox）

Valid pixels

640x480

Wave length

8～14μm

NETD

≤50mK@F1.0,300K

Frame

25Hz

Thermal imager

Focal length

100mm, 25-100mm 4X zoom, auto focus

FOV

6.2°×5.0°

Lens control

Electronic focus

Effect distance

To people≥2800m, to vehicle≥8000m

Control

Ip software

HD 1080P camera

Effecting Distance

1000m in daytime

Lens

Focal Length: f=4.5～135mm, 30x optical zooming

Lens aperture: F1.6~4.4

Video Code

Format: H.264

Video resolution: 1280×1080p(25fps), support dual-stream

Title on screen display: logo, date, time, alarm

Image adjustment: brightness, contrast, saturation

HK series support Hikvision platform

Imaging Components

1/2.8" Progressive Scan CMOS

Pixel: 2.1 MEGA

Low illumination: 0.1 LUX (color), 0.01LUX (black&white)

Network Protocol

TCP/IP, ARP, ICMP, FTP, RTP/RTCP, NTP, DNS, DDNS, SNMP, PPPoE, RTSP

Pan-tilt

Tilt speed

0°~30°/s

Pan speed

0°~22°/s

Presets

128

Scan speed

1 °/s

Cruise function

2 paths

Environment indicators

Working temperature

-25℃～+ 60 ℃

Storage temperature

-40℃～+ 85 ℃

Anti-vibration

150m/s² 11ms

Salt-fog proof

continuously spray fog for 48 hours under PH6.5-7.2

physics

Power consumption

≤30W

Weight

15.5Kg

Size

516.5×240×310mm

MTBF

≥10000hrs
